Tarot X8-II Uav Tl8X000-PRO Multi-Copter Frame

Shop for Tarot X8-II Uav Tl8X000-PRO Multi-Copter Frame at our factory. We offer high-quality products for your drone needs. Buy now!"
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Certifications
  • Trade Show
  • Company Profile
  • FAQ
Overview

Basic Info.

Model NO.
Tarot X8-II
Power Supply
Electric
Technics
Assembly
Material
Carbon Fiber
Type
Sprayer Parts
Model Number
Tarot X8-II
Color
Black
Usage
Crop/Pesticide Spraying
Condition
New
Application
Agriculture
Tank Capacity
10 Liters
Symmetrical Motor Axis Distance
1125mm
Arm Length
395mm
Arm Weight
122g
Net Weight
3.42kg
Diameter of Centre Plate
335mm
Clearance Height of Landing Gear
490mm
Battery Specifications
25c, 22.2V, 22000mha
6s Brushless Electric Adjustment
40A
Working Environment Temperature
10 ºC ~ 40 ºC
Transport Package
Carton
Specification
10L
Trademark
Tarot
Origin
Cn
HS Code
8807900090
Production Capacity
500PCS/Month

Product Description

Product Description:
New generation version of Tarot X8 Octa-axis UAV
Designed for professional aerial photography users
Equipped with new electric retractable foldable landing gear and umbrella-shaped foldable arm
More convenient and safe for the application oof integrated PCB board
8 axis provided sufficient power, enables the high stability of UAV when one arm out of work
3.42kg of total weight
Portable and light
31 minutes of no-load hovering

Product Specifications:
Symmetrical motor wheelbase: 1125mm
Foldable props specification: 16 inches
Arm length (arm to motor base centre): 395mm
Arm weight (arm plus motor base): 122g
Diameter of centre plate: 335mm
Clearance height of landing gear: 490mm
Battery specifications: 25C, 22.2v, 22000mha
6S brushless electric adjustment: 40A
No load hover time: 31min (21.0v remaining battery power)
Working environment temperature: 10 ºC ~ 40 ºC
Net weight: 3.42kg


Package Content:
Central integrated disk × one
Single arm( Φ twenty-five × 355MM) × 8
Motor base tl96027 ×8
Electric stand( Φ twenty-five × 425MM) × 2
Foot drive tl8x002-02 ×1
Battery board (275 × one hundred and ninety × 1.6MM) ×1
Material package × 6
instructions × 1


Reference number of relevant accessories (to be purchased separately):
Rotor specification: 1655 foldable props package tl100d07
BLDCM: 4114/320kv multi-axis brushless motor tl100b08
Brush free electric adjustment: hobby Wing 40A tl2923
Battery specifications: 25C, 22.2v, 22000mhA
X series carbon fibre pattern head cover TL8X008
