Basic Info.
Model NO.
A20L
Power Supply
Electric
Transport Package
Airline Box
Specification
20L
Origin
China
HS Code
842482000
Product Description
| Model | A-20L | A-30L | |||
| No. | Item | Parameter | Parameter | ||
| 1 | Rotor number | 4 axis | 4 axis | ||
| 2 | Dimension | 1475mm*W1465mm*H600mm | 1475mm*W1465mm*H700mm | ||
| 3 | Empty mass | Empty 23KG | Including battery 29KG | Empty 24.5KG | Including battery33KG |
| 4 | Maximum takeoff weight | 49KG | 63KG | ||
| 5 | Motor power | Rated 1925W*4 | Rated 2300W*4 | ||
| 6 | Rotor | Compound propeller 36 inch*4 | Compound propeller 40 inch*4 | ||
| 7 | Battery | Voltage 51.8V | Capacity 22000mAh | Voltage 51.8V | Capacity 28000mAh |
| 8 | Flight time | Unloaded 22′ | Fully loaded(49KG)9′ | Unloaded 22′ | Fully loaded(63KG)9′ |
| 9 | Load capacity | Spray tank 20L | Spreading tank 25L | Spray tank30L | Spreading tank40L |
| 10 | Spray tank | Material PE | Standard capacity 20L | Material PE | Standard capacity30L |
| 11 | Nozzle form | Centrifugal spraying | Centrifugal spraying | ||
| 12 | Liquid pump | Diaphragm | Diaphragm | ||
| 13 | Spraying flow | Rated 4L/min | Maximum 5L/min | Rated 4.5L/min | Maximum 5L/min |
| 14 | Spray wide | 4-8m | 4-10m | ||
| 15 | Operating speed | 1-8 m / s | 1-8 m / s | ||
| 16 | Efficiency | 6-13 hectares/hour | 10-16 hectares/hour | ||
