Carbon Fiber Frame Atomization Nozzle Agriculture Fertilizer Sprayer Drone

CarbonSpray AgriDrone: High-tech fertilizer sprayer drone with carbon fiber frame and atomization nozzle. Manufactured by our factory for precision agriculture.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
U25L-4
Volume
16L~30L
Power Supply
Electric
Technics
Assembly
Material
Aviation Carbon Fiber and Aviation Aluminum
Type
Sprayer Drone
Sprayer Type
Pump
Usage
Agriculture
Applicable Industry
Farms,Home Use,Epidemic Prevention
Feature
Anti-Fall
Production Material
Aviation Carbon Fiber and Aviation Aluminum
Production Folding Size
1860mm*1860mm*545mm
Max Pesticide Load
25kg
Aircraft Medicine Box Capacity
25L
Flight Radius
Less Than 5000m
Max Takeoff Weight
51kg
Aircraft Weight
19kg
Flight Attitude
Less Than 30m
Flight Duration
13-33minutes
Condition
New
Warranty Time
12 Months
Transport Package
Professional Package Box
Specification
1 CBM
Trademark
Brouav
Origin
China
HS Code
8802200090
Production Capacity
10000 Unit

Product Description

Carbon Fiber Frame Atomization Nozzle Agriculture Fertilizer Sprayer Drone
- OEM  & ODM Service -
 Model  U25L-4
 Product Material  Aviation carbon fiber + aviation aluminum
 Product Extended Size  1860mm*1860mm*545mm
 Product folding size  1080mm*1080mm*545mm
 Maximum takeoff weight  51KG
 Aircraft weight  19KG
 Pesticide Barrel  25L
 Flight altitude  ≤30m
 Fly time (unloaded)  20~25 minutes
Fly time (Loaded) Full load 10~18 minutes
Flight speed  0-20m/s
 Spray width  4-8m
 Hovering in the air  Hovering in any direction
 Spray flow  3-8L/min double pump adjustable
 Spray system  Imported high pressure anti-floating atomizing nozzle
 Atomization point size  60~500μm
 Fly Control  Industrial Version GPS and Controller
 Spray efficiency  10hectares / hour
 Safe takeoff and landing wind speed  ≤5 Level
Motor speed  5000rpm
Power system 60.9V power polymer computer battery
Intelligent Charer AC Input 100-240V
Lithium-polymer battery 22000mAh*1

Features
1. The fuselage adopts a closed design, which can prevent pesticides from entering the flight control system
and provide safety guarantee for long-term operation;
2. The plant protection machine has built-in GPS and compass module, with fixed-height and fixed-point flight
function, which can well maintain the spray height and spray route accuracy of the operation;
3. The height limit and flight speed limit of spraying operation can be set. The high-pressure spraying system
has good atomization effect. Under the wind pressure of the aircraft, the drug mist has the characteristics of
strong penetration. Leaf face.
4. Modular design of functional components, easy maintenance and upgrade.
5. Using intelligent plug-in battery.
6. Use quick-plug medicine barrel.
7. High-pressure brushless water pump is adopted, and the ESC is fully waterproof.
8. Wear the case, optimize the whole machine, and hide the medicine circuit.
9. 7075 aviation aluminum (high grade) is used for the folding part.
10. Alternating spraying function, the spray head can be switched independently.
11. The arm can be quickly disassembled.
So our drones are very popular.
