Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer

Get high-quality Big Capacity 30L Intelligent Drone Farming and Mosquito Spraying Drone for Paddy from a trusted manufacturer. We are a factory specializing in advanced agricultural drones.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • Detailed Photos
  • Our Advantages
  • Company Profile
  • Customers feed backs
  • FAQ
Overview

Basic Info.

Model NO.
JT30L-404
Warranty
One Year
Installation
External Thread Connection
Liquid Contained
Medicine
Spraying Shape
Full Cone
Volume
30L
Power Supply
Electric
Technics
Assembled
Material
Carbon Fiber
Type
Uav Drone Sprayer
Product
Agriculture Drone
Operation
Automatically Flying and Manual
Remote Controller
H12 RC with Screen
Application
Spraying Pesticide Liquid
Spreading Seeder
Yes
Spraying Span
8-10
Spraying Efficiency
12-15 Hectares Per Hour
Nozzles
2 PCS Centrifugal Nozzles
Battery Type
Quick Pluggable Battery Drone
Battery
14s 20000mAh Smart Battery Drone
Flying Speed
7m/S
Take off Weight
40kg
Self Weight
18 Kg
Spreading Size
W 2.9m X L 2.9 M X H0.78 M
Fold Size
W1.05m X L0.62 M X H 0.78m
Transport Package
Aluminum Packing Case
Specification
JT 30L-404
Trademark
JOYANCE
Origin
Made in China
Production Capacity
200 Sets / Month

Product Description


Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy manufacturer

Model: JT30L-404  AGRICULTURAL SPRAYER  DRONE



Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer


The latest modern design, smart appearance. The most competitive model of drone sprayer.

Aviation aluminum alloy drone frame, durable and stable;

Foldable drone sprayer arms, easy to transport;

Quick pluggable battery drone ;

Can be equipped with an optional granular spreader, for scattering and seeding;

14S 22000mAh smart battery, intelligent management system inside;

High-power fast charge, charging can be completed in 15 minutes;

H12 remote controller with night vision FPV camera;

Multilingual language App for flight routes planning;

Standard obstacle avoidance function.
Terrain the following function


Product Description





Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy ManufacturerBig Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer


With higher flight speed and greater spraying flow, the operation efficiency of JT 30L-404 can reach up to 14ha/hr, which is equivalent to the work of 100 farmland laborers and solving the aging problem of the rural population.


Spraying drone with two centrifugal nozzles

Volume: 10L/min
Maximum Effective Flight Speed: 12m/s
Maximum span: 10m
Spraying Volume: 10L/min

Maximum Effective Ft Speed: 12m/s
Maximum spraying span: 10m

Product Parameters


      JT 30L-404   agricultural drone technical parameters sheet

Model JT30L-404 drone
Pesticide Tank 30L
Net Weight 20.8 kg
Take-off Weight 59  kg
Max take-off weight  68.3KG
Flying Time 10~15min
Flying Radius 0~1000m
Flying Height 0~30m
Flying Speed 0~12m/s
Work Temperature -10~70°C
Work Humidity 0~90%
Spray Speed 0~8m/s
Spray Width/Nozzle No. >8~10m / 2 centrifugal Nozzles
Spray Flow 7L/min
Spray Efficiency 12~15Ha/Hr
Flying Downward Airflow 4~15m/s
Wind Resistance 10m/s
Machine Size W 2.9m x L 2.9 m x H0.78 m
W1.05m x L0.62 m x H 0.78m
Power System FOC X11  PLUS
Flight Controller  JIYI K++ V2
Remote Controller  H12 RC with 5.5" screen app
Battery / Quantity 14S 22000mAh / 1pc
Pump  Double brushless pump
Adapter + Charger Dual-Channel Charger 3000W
Packing Case Aluminum Case
Toolkit Maintenance/Repair Tools
Terrain following radar  terrain following
Obstacles avoiding sensor  front and back sensors optional
FPV  Camera with night light
Spreader tank  scattering grass seeds, sowing seeds, feeding, fertilizer, deicing agent, etc





Features of model JT30L-404 drone
Large power 4 pcs X11 plus motor, large propellers 43 inch
Small battery 14s 22000mah, low use cost, complete set price is low, battery cost low
 Fashionable appearance, Novel design, and waterproof  IP56.
The whole drone frame is made from aluminum alloy, which less weight but is the more durable and firm, long life span
Small drone size, easy to deliver and transport
Adopt a smart battery, with high energy density, support fast charge, and longer life. Built-in battery management system, easy to manage and maintain.
Fast-charging charger, fast charging speed, reducing the number and cost of battery purchase.
Stable downward pressure wind field,  not roll up, best spraying effect larger spraying width,  small drift,  no spray leakage.
Centrifugal nozzles 2pcs, better-spraying atomization effect, suitable for fruit trees, droplet size 50-100 um.




Características del dron modelo JT30L-404
Motor de gran potencia 4 piezas X11 plus, hélices grandes de 43 pulgadas
Batería pequeña 14s 22000mah, bajo costo de uso, el precio del conjunto completo es bajo, el costo de la batería es bajo
Apariencia de moda, diseño novedoso e impermeable IP56.
Marco de dron completo hecho de aleación de aluminio, menos peso pero más duradero y firme, larga vida útil
Tamaño de dron pequeño, fácil de entregar y transportar
Adopte una batería inteligente, alta densidad de energía, soporte de carga rápida, vida más larga. Sistema de gestión de batería integrado, fácil de gestionar y mantener.
Cargador de carga rápida, velocidad de carga rápida, reduciendo el número y el costo de la compra de la batería.
Boquillas centrífugas 2 uds, mejor efecto de atomización de pulverización

Detailed Photos



Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer

Model JT30L-404 drone sprayer including :

Complete reply to fly drone sprayer,
Remote controller H12 with screen and app
Obstacles avoidance radar
1 pcs battery 14s 22000mah
1 pcs dual-way quick charger
Ultrasonic flow meter, more accurate
Camera
Aluminum packing case
Tool kit case


For continuous working with the drone sprayer, we advise buying an extra 3 pcs batteries and one extra charger.

Centrifugal nozzles drone sprayer has a better spraying effect than normal high-pressure nozzles, more suitable for fruit trees, etc, with droplet sizes 50-100um.

Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer



Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer
Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer
Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer


1. It can install a spreader tank for spreading solid seeds and fertilizers
spreader drone tank capacity of 35L

2. Durable drone frame made from aluminum alloy, durable, can use for five years
3. Large motor power, thick carbon fiber tubes, more firm drone.




Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer
The drone is equipped with terrain following radar, obstacles avoidance radar, camera with app and automatically flying app. easy to operate for every one .
Smart batteries and fast charger can charge one battery in 15 minutes, quick pluggable battery drone sprayer, durable and not easy to break.
Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer
Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer
Foldable drone design, small space, convinient to delivery



Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer

For our 30L-404, it is equipped with newest Ultrasonic Double Tube Flow Meter with
following features:

1. Non-contact detection, stable and reliable

2. More accurate when recording break point

3. More convenient to install, easy to maintain, and has a long service life.

Precise spraying flow range for JT30L-404:
15L/hectare-60L/hectare.

4. No change of flow state, no pressure. Good at measuring highly corrosive pesticides.

5. Advanced ultrasonic probe and ingenious structural design can achieve ± 3% flow
detection accuracy

6. Resist noise and high-speed vibration. Perfect for drone sprayers.

For old type flow meter, less precision, shorter life span, easy to block, easy to corrode.
Now most of other drone factory use the ordinary flow meter.


  • agriculture drone sprayer,
  • ag drone sprayer,
  • agricultural spraying drone,
  • agriculture drone for spraying,
  • agriculture drone spraying,
  • crop spraying drone,
  • drone spraying agriculture,
  • pesticide drone spraying


Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy Manufacturer

Our Advantages

Medidor de flujo ultrasónico de doble tubo

Detección sin contacto, estable y confiable.

Más preciso al registrar el punto de quiebre

Más conveniente de instalar, fácil de mantener y tiene una larga vida útil.


Sin cambio de estado de flujo, sin presión. Bueno para medir pesticidas altamente corrosivos.


La sonda ultrasónica avanzada y el ingenioso diseño estructural pueden lograr una precisión de detección de flujo de ±3 %

Resiste el ruido y la vibración de alta velocidad.

Perfecto para pulverizadores de drones.




Medidor de fluxo de tubo duplo ultrassônico






Company Profile

Big Capacity 30L Intelligent Drone Farming, Mosquito Spraying Drone for Paddy ManufacturerJoyance Drone Agriculture Sprayer

Latest sprayer drone technology, ready to fly(RTF), foldable drone arms, remote control, autopilot by App for flight routes planning, with GPS, with night vision FPV camera, with obstacle avoidance radar......
Joyance Tech, an agricultural spraying drones factory in China, focuses on agriculture drone, drone agriculture sprayer, agriculture drone sprayer, aerial farming sprayer drone, pesticide spraying drone, UAV crop duster drone, fumigation drone, fertilizer and seeding drone, fertilizer scattering drone, thermal fogging drone and biological control drone research, development and production since 2016. Joyance drones have wide prospect in application to precision agriculture, plant conservation, disinfecting and sanitizing.



Core value


Customer-first, attentive service

JOYANCE have users from more than 90 countries in the world, we are here to provide immediate service at any time when they need it. We provide in-time after-sales service and all-life technical support to let users feel safe. They will be sincerely treated during the use of Joyance drone sprayers.
JOYANCE

Global vision
We keep developing new products to meet the requirements of users and keep updating drone sprayers' functions and features to meet development of a modern smart agriculture ecosystem. Follow the development of the times, maintain progress, and lead technological innovation.


Professional commitment
We will Persist promises to our partners and clients, dare to overcome difficulties and say NO to great temptation. As professional company, we will try our best to meet clients needs and to be honest at any time.


Pursue practicality

No matter for drone frame, or for drone functions, we aims to practicality of drone sprayer in daily use in the farm. Our users are farmers, and we provide a great tool to help their work. So the drone must be durable, easy to maintain, low repair cost, and long time use.


Customers feed backs






FAQ




Q1. Are you a sprayer drone factory?

A1: Yes, we are a professional manufacturer of sprayer drones.

Our main products are agricultural sprayer drones and spreader drones. thermal fogger drones, biological control drones.

Q2. Is the UAV sprayer drone ready to fly?

A2: Yes. Before dispatch, JOYANCE assembles all the parts and set all the parameters. Every drone is 100% flight tested and has strict quality control.

Q3. What`s your MOQ for an agricultural drone?

A3: MOQ ≥1. More than 100 units of order is available. Besides, we are looking for dealers and agents all over the word. Welcome to contact us for more details.

Q4. What`s the delivery time of the sprayer drone?

A4: 7 days for one, please contact us for mass order.

Q5. What`s your payment term?

A5: 50% payment as deposit, balance before delivery.
