Basic Info.
Model NO.
D16L-4
Power Supply
Electric
Technics
Assembly
Material
Aviation Carbon Fiber and Aviation Aluminum
Type
Sprayer Drone
Sprayer Type
Pump
Usage
Agriculture
Applicable Industry
Farms,Home Use,Epidemic Prevention
Feature
Anti-Fall
Production Material
Aviation Carbon Fiber and Aviation Aluminum
Production Folding Size
730mm*730mm*635mm
Max Pesticide Load
16kg
Aircraft Medicine Box Capacity
16L
Flight Radius
Less Than 5000m
Max Takeoff Weight
36kg
Aircraft Weight
12.7kg
Flight Attitude
Less Than 30 Meters
Flight Duration
20-25 Minutes
Condition
New
Warranty Time
12 Months
Transport Package
Professional Package Box
Specification
1 CBM
Trademark
BROUAV
Origin
China
HS Code
8802200090
Production Capacity
10000 Unit
Product Description
16kg agriculture pesticide sprayer drone for sale
- OEM & ODM Service -
Product Description
Remote control eye escort
D16L-4 supports digital image transmission technology, and the remote control range can reach 3,000 meters.Equipped with wide-angle FPV camera and night searchlight, it can monitor the aircraft operating environment to ensure operation safety.
Product Specifications
BROUAV adopts industrial grade hardware structure and sensors, available for more communication modes.
Product Specifications
BROUAV adopts industrial grade hardware structure and sensors, available for more communication modes.
| Model | D16L-4 |
| Product Material | Aviation carbon fiber + aviation aluminum |
| Airframe Dimensions(Incl. propellers) | 1870*1870*635mm |
| Airframe Dimensions(folded) | 730*730*635mm |
| Transport Dimensions | 900*780*650mm |
| Max Takeoff Weight | 36KG |
| Aircraft Weight | 16KG Excluding Battery |
| Maximum Capacity(spraying system) | 16L |
| Flight Altitude | ≤30 meters |
| Flight Time (Unloaded) | 10~20 minutes |
| Flight Time (Full Loaded) | 6~10 minutes |
| Flight Speed | 1-10 m / sec |
| Spray Width | 4-8 meters |
| Spray Flow | 2-5L/min double pump adjustable |
| Nozzle Type | Imported high pressure anti-floating atomizing nozzle |
| Droplet Size | 60~500μm |
| Flight Controller | Industrial Version GPS and Controller |
| Navigation Method | GPS/GNSS RTK |
| Operating Efficiency | ≥8(ha/hr) |
| Safe Takeoff and Landing Wind Speed | ≤8 m/s |
| Motor speed | 5000rpm |
| Battery Voltage | 60.9V |
| Battery Capacity | 20000mAh*1( 14S Intelligent Lithum Battery) |
Features
1. The fuselage adopts a closed design, which can prevent pesticides from entering the flight control system and provide safety guarantee for long-term operation;
2. The plant protection machine has built-in GPS and compass module, with fixed-height and fixed-point flight function, which can well maintain the spray height and spray route accuracy of the operation;
3. The height limit and flight speed limit of spraying operation can be set. The high-pressure spraying system has good atomization effect. Under the wind pressure of the aircraft, the drug mist has the characteristics of strong penetration. Leaf face.
4. Modular design of functional components, easy maintenance and upgrade.
5. Using intelligent plug-in battery
6. Use quick-plug medicine barrel
7. High-pressure brushless water pump is adopted, and the ESC is fully waterproof.
8. Wear the case, optimize the whole machine, and hide the medicine circuit.
9. 7075 aviation aluminum (high grade) is used for the folding part.
10. Alternating spraying function, the spray head can be switched independently.
11. The arm can be quickly disassembled.
Don't puncture the battery. If the battery pack is drummed, there is a safety hazard. Especially when charging, the drum pack should be stopped immediately and the battery should be moved to a safe place.
